DR DN Electric Fusion Sheet Applying To Seal The

DR DN Electric fusion sheet applying to seal the joint of plastic drain pipe 1. Components Electric fusion sheet Plastic filling stick 2. Main installation facility Electric fusion machine Electrical machine Lock strap Clamp 3. Application The range of Electric fusion sheet is to suit all plastic drain pipe sizes. Among them, DR DN series and DRF DN series are suitable for the connections of flat wall pipes. Moreover; DRF DN series are special applicable in non-digging project. And DRGD DN series are special applicable for the connection of steel reinforced polyethylene spiral corrugated pipe which can enhance the mechanical strength of the joint, but not seal. 4. Features ---- Electric fusion sheet is based on a unique polyethylene material, which has an excellent mechanical strength and long application life. Its powerful penetrating resistance and superior mechanical toughness can resist impact of soil and stone during installation and use. ----The special resistance web embedded in the inner surface of the material can incorporated the electrical fusion sheet in pipe, so that the reliability of the joint is excellent. All the materials are innocuous and no corrosive. Pollutant and castoff will not be produced in application, which is satisfied with the requirements of environmental protection. 5. Nomenclature Dimensions in mmDR (F) (GD) DN D × L L------Axial length of sheet D------Inner diameter of pipe DN------Code of inner diameter of pipe GD------DRGD DN series are special applicable for the connection of steel reinforced polyethylene spiral corrugated pipe F------DRF DN series are special applicable in non-digging project DR------Electric fusion sheet Axial Length and Thickness of SheetDimensions in mm Inner diameter of pipe (DN)Axial length (recommend)ThicknessFlat wall pipessteel reinforced polyethylene spiral corrugated pipeDN≤350200---6.5350<DN≤500300---6.5500<DN≤80035055 657.5800<DN≤120040055 658.51200<DN≤160045055 658.5DN>1600450 50055 6510.5
